DIY Desktop mainboard Onboard 13th Core CPU Q1J3(i7 ES 0000)12C16T Iris Xe DDR5
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Socket Type | Onboard cpu |
| CPU Technics | 12 Cores 16Threads |
| 2 Slot A | M.2 NVMe |
| Input/Output Ports | USB 2.0 |
| MPN | Does Not Apply |
| Most Suitable For | Gaming |
| Memory Type | DDR5 |
| Motherboard Brand | SEE |
| Form Factor | Micro-ATX (215*175MM) |
| Manufacturer Warranty | 3 Months |
| SATA Slots | 2 * SATA 3.0 |
| CPU L3 Cache | 18MB |
| Features | On-Board Audio |
| CPU Series | Core i7 |
| Compatible CPU Brand | Intel |
| Power Supply Connectors | 24PIN |
| Model | Q1J3 ES 0000 |
| Lan | Max LAN Speed :2500Mbps |
| Board Size | 215*175MM |
| CPU Clock Speed | 2.2Ghz |
| Graphics Type | Iris Xe Graphics |
| Country/Region Of Manufacture | China |
| Basic Consumption | 28W |
ATX DIY Desktop Motherboard with Onboard 13th Kit Interposer Core CPU Q1J3(i7 ES 0000)12C16T Iris Xe Graphics DDR5 RAM Important:Due to the unpredictable negative feedback for the PCIE Slot, So, we have removed the discrete video card slot.The onboard CPU is a ES(Engineering sample) processor, on CPU-Z, It shows"0000".The following test data is just for reference, which can't be used as ajudgment standard. Everything please refer to your actual test environment.If you place order, It means you are aware of the issue by default.Please read carefully before purchasing.DDR5 RAM Compatibility issues notification:Due to the unique nature of the MODT platform, RAM memory plan is a challenging task.Currently. Our DDR5 MODT platform is not compatible with some of 32GB RAM memories.If you need to use 32GB of single memory, please choose carefully or ask us before place order.For the frequency,usually we recommend to use DDR5 memory with frequencies of 4800Mhz and 5200Mhz to keep stable.our motherboard can Supports up to 5600 (XMP overclocking) Mhz, but we recommend only using Hynix's original unmarked(not relabled memory).(TIPs: We do not recommend using any memory from Gloway and Asgard brands)Thank you so much for your understanding!
