285 CFM 12V 2.5A Ultra High Airflow MINER SERVER FAN 120x38mm 3-Pin PWM Control
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| Bearing Type | Ball |
| Color | Black |
| Material | Plastic |
| Maximum Airflow Volume | 285 CFM |
| MPN | DCH12038HV12B |
| Item Length | 120mm |
| For Use In | Bitcoin Mining Servers |
| To Fit | 120x120x38mm |
| Fan Light Color | NONE |
| Brand | TKFAN |
| Fan Diameter | 120 mm |
| Form Factor | Bitcoin Mining Servers |
| Type | Case Fan |
| Power Connection | 3-Pin |
| Unit Type | Unit |
| Item Height | 38mm |
| Maximum Fan Speed | 5200 RPM |
| Voltage | 12 V |
| Packaging | Bulk |
| Country/Region Of Manufacture | China |
| Item Width | 120mm |
DCH12038HV12B 12VYOU ARE BUYING 1 SERVER GRADE 12V 2.5Amp FAN Ultra High Airflow Fan used in Servers, Bitcoin Servers, Mining Servers, Mining Rigs, Gaming Computers, Pro Amplifier Cooling, etc. Can be used as a regular 2-wire 12V fan by connecting only the Black (-) and Yellow (+) wires to 12VDC @ 2.5 Amps then the fan will work at its highest speed of 5200rpm (285 CFM). Dimensions: 4.72" x 4.72" x 1.5" (120 x 120 x 38mm)Rated Voltage: 12VDCOperating Voltage: 8VDC - 13.5VDCInput Current: 2.5 Amps *(You need 2.5A per fan, otherwise they won't reach top speed!)*For example: If you connect 4 fans together, you need a 12V @ 10A (UL Approved) power supply to reach full Speed) RPM: 1,500 to 5,200 RPMAirflow: 285 CFM (@ Max speed)Noise Level: 72 dB (@ Max speed)Bearing: Ball bearings (Can be installed vertically or horizontally!)Power Connector: 3 pin (Pins can be repositioned in the plug to match your wiring configuration)PWM Speed Control (Blue Wire)Input Power: 30 WattBrand: TKFAN
